VOLVO Penta 250KW Diesel Generator Price Global Warranty 250kw
Power Generator Volvo 312.5kva Diesel Generator Set
Volvo TAD1344GE diesel generator sets features:
| Product Overview | |
| 1) Brand-new engine,w/start motor. | |
| 2) Brushless alternator,single bearing,flange connection,IP23,H
insulation class,with AVR. |
| 3) Auto control panel with LCD display. | |
| 4) Engine mounted battery-charging alternator,Genset with battery
charge of main supply. |
| 5) Circuit Breaker,Exhaust Silencer. | |
| 6) Copper Radiator for 40℃ ambient temperature and double-deck
cooling,with fan guard and front guard. |
| 7) Anti-vibration pads fixed between engine/alternator and base
frame to ensure the compete genset running stable. |
| 8) Skid-mounted bottom 8 hours fuel tank. | |
| 9) Extemal recessed emergency stop button for extra safety. |
| 10)Optional:Soundproof,ATS(automatic transfer switch),AMF
panel,Trailer,Parallel system. |
| Genset Specification |
| Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd |
| Model | MB-330 |
| Prime Powder | 329KW/411.25KVA |
| Standby Powder | 362KW/452.5KVA |
| Power Factor | COSΦ=0.8(lagging) |
| Max. Output current | 594A |
| Genset Weight | 2950KG(Net) |
| Length x Width x Height (Engine) (mm) | 2950*1150*1600mm |
| Voltage | 400/230V |
| Frequency | 50HZ |
| Engine Specification |
| Manufacturer | Volvo Engine Co. Ltd |
| Model | TAD1344GE |
| Rated speed | 1500rpm |
| Prime Powder | 354KW/442.5KVA |
| Standby Powder | 389KW/486.25KVA |
| Fuel Consumption | ≤198g/kw.h |
| Lube oil capacity | 35L |
| Bore (mm) x Stroke (mm) | 131*158mm |
| Compression ratio | 18:01 |
| Displacement (litre) | 12.78L |
| Coolant capacity, L | / |
| Configuration | 6 in line ,four-stroke, Turbocharged, Charge Air Cooled |
| Cooling | Liquid Cooled |
| Governor type | diesel management system EMS2 |
| Starting voltage | 24 Volts DC |
| Fuel system | Full electronic fuel injection system (fuel common rail) |
| Filtration system | Air Filter/Fuel Filter/Oil Filter |
| Alternator Specification |
| Manufacturer | Jiangsu Mingbang Intelligent Technology Co.Ltd |
| Model | MBC5A |
| Voltage Regulator | AVR |
| Voltage adjust range | ±1% |
| Rated Voltage/Frequency/Factor | 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire |
| Steady-state Frequency | 5% |
| No-load Voltage Adjust Range | >=95%-105% |
| Insulation Class | H |
| IP Protection | 22 |
| Excitation Type | Blushless |
| Rated power | Engine | Alternator | Control panel |
| 24kw~1500kw | Cummins | Stamford
Leroy somer
Marathon
Mecc alte
ABB
Chinese alternators | Deepsea
ComAp
Harsen
Smartgen |
| 36kw~18+00kw | Perkins |
| 68kw~560kw | Volvo |
| 20kw~200kw | Deutz |
| 40kw-2200kw | Yuchai |
| 50kw-2200kw | Weichai |
| 540kw-1900kw | Mitsubishi |
| 50kw-800kw | SDEC |
| 650kw~2200kw | Chinese engine |
Our factory
Mingbang Co.,Ltd is devoted to the R&D and manufacturing of
diesel generator sets since its establishment in 2008 ,Wetech
accumulates a wealth of experience in the manufacturing and
maintenance of generator sets field. Our production capacity
amounts to 4000 sets per year. Wetech production are submit to
ISO8525, GB/T2820-97 and CE certification, and quality certified by
ISO9001 & ISO14001 Management System to guarantee high quality
products and service.
China Most Professional Silent Type 412kva Volvo Penta Diesel
Generator Factory With CE
We deliver all of our diesel generators on time. The diesel
generators are packed by standard sea freight rules or according to
customers' requests. We make sure that our diesel generators are
safe during transportation.
We have exported to over 40 countries and regions, including the
USA, Russia, Australia, Ukraine, Pakistan, Philippines, Myanmar,
Cambodia, South Africa, Kenya, Zambia, Kuwait, UAE, Dominican,
Ecuador, Venezuela, Panama, etc. Our diesel generator sets are
widely used in Mines, Railways, Field construction sites, Road
traffic maintenance, Schools, Residences, Shopping malls, as well
as Factories, Enterprises, Hospitals, Data centers, Communications,
and other departments, as a backup or temporary power supply.
Our Customer
More details for diesel generator sets ,please contact us any time
Your further inquiry will be welcome!!
